Sunstone

20" Sunstone Appliance Cabinet w/Left Swing Door

Regular price $1,259.00 USD
Regular price Sale price $1,259.00 USD

The 20 In. Sunstone Appliance Base Cabinet is uniquely designed to receive multiple Types of either Double Slide-In Side Burners or Bar Stations of many industry Brand Models right out of the box with easy installation. The cabinet comes standard with a Left-Swing Side Door Enclosure for a Trash Bin or Propane Tank Storage. There is a Bottom Utility Access Port as well, located behind the bottom a Slide Out Tray. The cabinet comes Fully Assembled, only requiring to fasten on the four included Peg-Legs, screw in place each 304 SS Rod Handles, and mount the Front and Back Kick-Plates. This Cabinet makes use of a “TRIM-KIT” that is installed on the front face of the cabinet, which adapts the cabinet to fit your preferred appliance, and is compatible with “CUT-OUT” Sizes between 9-3/4 In. to 14-1/2 In. Width by 8 In. to 10-1/4 In. Height with a counter at 3/4" Height with Filler Rail installed or removed. Additional Height can be adjusted by Removing Bottom Filler Rail or by adding a Thicker Counter or Backer Board. Please Specify the Correct “TRIM-KIT” to be included with the cabinet to fit your product, if your Side Burner or Bar Station is any of our Models we will automatically include the correct Trim-Kit. Please refer to the Cabinets Specification Sheet for more information, see the second page showing the various insert sleeve dimensions this refers to your products “Cut-Out” Dimension – match this up to the correct “Trim-Kit” and specify this piece on your order.

  • Lifetime Structure Warranty   • 304 Stainless Steel Structure
  • 304 SS Rod Handles   • Front Vented Kick-Plate
  • Rear Solid Kick-Plate   • Replaceable Face Panel
  • Easy Pin-Lock Installation   • Removable Counter Rail
  • Covered Side Wall Access Ports   • 4 Adjustable Peg-Legs
  • Optional Wheel Casters


Separately purchase the Side Cabinet End Panel & End Kick-Plate



SAC20CSDL TRIM-KIT
Item Number Sleeve Cut-Out Product Option
SCC20CTK2.5 14-1/2" Width x 10-1/4" Height x
24-1/2" Maximum Depth

SCC20CTK3.25 13-1/2" Width x 10-1/4" Height x 24-1/2" Maximum Depth Sunstone® Cocktail Station, Sunstone®
Cocktail Pro, Alfresco® Double Burner
SCC20CTK3.75

12-3/8" Width x 8" Height w/Rail or
10-1/4" Height wo/Rail x 24-1/2" Maximum Depth

Sunstone® Double Burner, Double Burners for - RCS®, Lynx®,DCS®, Alfresco®, Luxor®, Cal-Flame® Double Burner, Cal-Flame® Cocktail Center, Coyote® Double Burner
SCC20CTK4.5 11" Width x 8" Height w/Rail or 10-1/4" Height wo/Rail x 24-1/2" Maximum Depth Steele® Side Burner
SCC20CTK5 9-3/4" Width x 8" Height w/Rail or 10-1/4" Height wo/Rail x 24- 1/2" Maximum Depth
20" Appliance Cabinet w/Left Swing door Insertable Products
20"W x 28-1/4"D x 34-1/2"H (w/Legs) Double Side Burner -2CSB
20"W x 28-1/4"Dx 30-1/2" (without Legs) Cocktail Pro- B-CS14
Upto 36" Max Adjustable Height
Net Weight 71.5 LBS
23"W x 31" L x 33" H(Package Size)/81
Download Cabinet Island Setup Manual
Download Spec.Sheet for SAC20CSDL
Material Specifications:
304 Stainless Steel entire structure, 18 Gauge for Door Panel , 18 Gauge for Cabinet Box, 18 Gauge for Shelf, Handles are made of Solid 304 Stainless Steel Bar
Disclaimer: The trademarks used in the “Product Option” column below belong to their respective owners. Use own discretion to confirm exact product fit.
